Sewage treatment, iron and steel metallurgy, mining, chemical industry, gas production and large air volume air conditioning system,
and long-term for blower manufacturers supporting use. In order to meet the different air volume needs of users, the filter unit can
be used alone, and multiple units can be combined into a row of filter units, and it can also be designed and manufactured
according to the needs of users and the actual working conditions on the site.
|
Total filter width Feet (mm) |
Rated air volume m³/h |
|||||
|
Filter height feet (mm) |
||||||
|
10(3048) |
11(3353) |
12(3658) |
13(3962) |
14(4267) |
15(4572) |
|
|
3(914) |
19800 |
21900 |
24000 |
26200 |
28300 |
30000 |
|
4(1219) |
24600 |
29200 |
32000 |
34900 |
37700 |
40000 |
|
5(1524) |
33000 |
36500 |
40000 |
43625 |
47125 |
50000 |
|
6(1829) |
39600 |
43800 |
48000 |
52350 |
56550 |
60000 |
|
7(2134) |
46200 |
51100 |
56000 |
61075 |
65975 |
70000 |
|
8(2438) |
52800 |
58400 |
64000 |
69800 |
75400 |
80000 |
|
9(2743) |
59400 |
65700 |
72000 |
78525 |
84825 |
90000 |
|
Structure description: |
|
|
Frame: Aluminum alloy, 304 stainless steel |
Lightweight and high strength |
|
Upper and lower filter material box: sprayed steel plate, 304 stainless steel |
Strong corrosion resistance |
|
Filter tank, filter shaft: 304 stainless steel |
|
|
Filter material inlet and outlet air surface protection net: 304 stainless steel wire |
Strong corrosion resistance |
|
Hand plate: cast iron, chrome plated surface, 304 stainless steel |
Integrated shape, strong and reliable |
|
Filter material: G3/g4/m5(EN779) |
Stable efficiency, low resistance |
|
Loading box damping system: shrapnel combination device |
Can prevent self weight feed |
|
Speed regulating and decelerating mechanism |
Easy refuelling in running condition |
|
Motor: 220V,180W, decelerating motor |
Smooth operation, energy saving (automatic selection) |
|
Display: Siemens 4 "large screen LOGO display |
Full Chinese menu display (automatic selection) |
|
Display device running status (optional) |
|
|
Control function: filter material replacement alarm, motor failure report |
Flexible control (automatic selection) |
|
Pressure difference control status alarm |
|
|
Gear: automatic control, manual control |
Powerful (automatic selection) |
