Temperature: ≤70℃
Humidity: ≤95%RH
Features Include:Large Surface Area,Excellent Adsorption High Quantitiesofactivated Carbon.
Good Ventilation Performance.Low Pressure Drop.Long Service Lire.Low Cost
Effective Absorption Of Industrial Exhaustgas,E.G., Benzene,Toluene,Xylene.Acetone,Oil
Abd Gas.Sulfur Dioxide,C32.And Other Organic Solvents
Avariety Of Sizes.Dimensions. And Specifications 8Re Available.
Carbon Activated Filters Are Widelv Used In The Chemical Industry.Pha Rmaceutlcals,Paints Leather Production ,And Heavy Industries To
Deodorize And Disinfect The Air.
|
Type (mm) |
WxHxD (mm) |
WxHxD (mm) |
Area (m²) |
Airflow (CMH) |
InitialPressure (Pa) |
Airflow (CMH) |
InitialPressure (Pa)※ |
|
|
12x24x1 |
290x594x20 |
0.28 |
930 |
|
1550 |
90 |
|
Carbon activated pleat |
20x24x1 |
490x594x20 |
0.47 |
1580 |
65 |
2650 |
|
|
24x24x1 |
594x594x20 |
0.56 |
1900 |
3180 |
|||
|
12x24x2 |
290x594x46 |
0.46 |
930 |
45 |
1550 |
65 |
|
|
20x24x2 |
490x594x46 |
0.72 |
1580 |
2650 |
|||
|
24x24x2 |
594x594x46 |
0.92 |
1900 |
3180 |
|||
|
12x24x4 |
290x594x92 |
0.84 |
930 |
35 |
1550 |
50 |
|
|
20x24x4 |
490x594x92 |
1.40 |
1580 |
2650 |
|||
|
24x24x4 |
594x594x92 |
1.68 |
1900 |
3180 |
|||
|
Granlar activated carbon |
24x24x1 |
594x594x20 |
|
|
|
|
|
|
|
|||||||
|
24x24x2 |
594x594x46 |
|
|
|
|
|
|
|
|
24x24x4 |
594x594x92 |
|
|
|
|
|
